SX-4L
Suxin
9405429000
Unique features：
1、This device adopts fully enclosed structure and streamlined design, high definition rippled panel is made of shock-resistant and heat-resistant PC material. In the reflector system designed in CAD/CAM, the depth of illuminance reaches up to 1000mm, by using color temperature compensation technology, the color reversion is upraised, and it is more suitable for the illumination of the complex surgery such as encephalon surgery and thorax surgery, therefore the well-proportioned illumination effectively eliminates shadows under any circumstance. It is an ideal lighting facility for surgical operation.
2、Micro-computer digital control circuit, with eight steps dimming, the major and auxiliary bulbs can be replaced easily. When the main bulb malfunctions, the standard bulb will come into operation automatically within 0.2 seconds，it also has brightness memory, wide voltage working feature, strong anti-interference ability and soft starter features. The service life up to 3000 hours, the detachable disinfection handle can be sterilized at a high lever≦134℃ to ensure reliable operation of the equipment. Six group joints move together and moves smoothly, positions stable, universal design can satisfy various needed height and angle in the operation.
Technical parameter：
Illuminance | 35000-100000 |
Color Temperature(K) | 4300K±500K |
Spot Diameter MM | 100-160mm adjustable |
The depth of the irradiation (MM) | ≥1000mm |
Brightness adjustment | Eight |
Temperature at surgeon's head | ≤1℃ |
Power supply and voltage | 220V 50Hz |
Bulb power | 150/150 |
Color Rendering Index (CRI) | ≥97﹪ |
Rated power of bulb（mw/m2lux） | 3.7 |
Configuration：
No | Item Name | QTY | Unit |
1 | 500 lampholder | 1 | set |
2 | Disinfection handle | 1 | pc |
3 | Halogen bulb | 4 | pcs |
4 | Spring Arm | 1 | set |
| 5 | Fixed base | 1 | set |
6 | Shield | 1 | set |
7 | Light tools | 1 | set |
8 | Operating manual/warranty card | 1 | set |
Unique features：
1、This device adopts fully enclosed structure and streamlined design, high definition rippled panel is made of shock-resistant and heat-resistant PC material. In the reflector system designed in CAD/CAM, the depth of illuminance reaches up to 1000mm, by using color temperature compensation technology, the color reversion is upraised, and it is more suitable for the illumination of the complex surgery such as encephalon surgery and thorax surgery, therefore the well-proportioned illumination effectively eliminates shadows under any circumstance. It is an ideal lighting facility for surgical operation.
2、Micro-computer digital control circuit, with eight steps dimming, the major and auxiliary bulbs can be replaced easily. When the main bulb malfunctions, the standard bulb will come into operation automatically within 0.2 seconds，it also has brightness memory, wide voltage working feature, strong anti-interference ability and soft starter features. The service life up to 3000 hours, the detachable disinfection handle can be sterilized at a high lever≦134℃ to ensure reliable operation of the equipment. Six group joints move together and moves smoothly, positions stable, universal design can satisfy various needed height and angle in the operation.
Technical parameter：
Illuminance | 35000-100000 |
Color Temperature(K) | 4300K±500K |
Spot Diameter MM | 100-160mm adjustable |
The depth of the irradiation (MM) | ≥1000mm |
Brightness adjustment | Eight |
Temperature at surgeon's head | ≤1℃ |
Power supply and voltage | 220V 50Hz |
Bulb power | 150/150 |
Color Rendering Index (CRI) | ≥97﹪ |
Rated power of bulb（mw/m2lux） | 3.7 |
Configuration：
No | Item Name | QTY | Unit |
1 | 500 lampholder | 1 | set |
2 | Disinfection handle | 1 | pc |
3 | Halogen bulb | 4 | pcs |
4 | Spring Arm | 1 | set |
| 5 | Fixed base | 1 | set |
6 | Shield | 1 | set |
7 | Light tools | 1 | set |
8 | Operating manual/warranty card | 1 | set |
